Woodpecker Endo Pace Brushless Endomotor
Woodpecker Endo Pace is a compact cordless brushless endomotor for clinics that value a lightweight working end. The documented handpiece and contra-angle weigh 106.8 g together. Adjustable drive settings and a small head support a planned preparation sequence; electronic length feedback can be added through a matched external locator where the configuration supports that connection.
Woodpecker Endo Pace: a preparation motor with a lightweight working end
The catalogue lists a combined handpiece and contra-angle weight of 106.8 g for Endo Pace. This is the working instrument weight, which is useful when evaluating handpiece handling. It should not be confused with the shipping weight of the complete boxed set. The cordless arrangement removes a trailing motor cable from the working instrument, while the brushless motor provides the drive for canal preparation.
Head dimensions and orientation matter in daily use
Woodpecker Endo Pace has a mini 6:1 contra-angle. The catalogue specifies a 9.7 mm head height, 8 mm head diameter and 6 mm neck diameter, with 360-degree rotation. These details help a clinician assess the physical access and operating view provided by the head. Consider the handpiece orientation in the actual working position, including how clearly the display and controls can be seen during use.
Choose the drive programme around the file instructions
Published settings include a speed range of 100–1500 rpm and torque from 0.4 to 4.2 Ncm. The catalogue also describes adjustable forward and reverse reciprocating angles for the applicable configuration. Match these capabilities to a defined file system, checking movement direction and recommended parameters. A motor with several available settings still requires deliberate selection by the clinician for the instrument and preparation stage being used.
Add measurement through a matched external locator
The Endo Pace manual describes connection to a matched external apex locator to add a measuring arrangement. This is different from assuming that a standalone motor package includes an integrated locator. A clinic planning connected operation should specify the locator, appropriate connection components and the supported motor functions together. Confirm the exact combination before purchase, so the preparation motor and measuring device are selected as compatible parts of the intended setup.
Specifications for Woodpecker Endo Pace
| Motor | Brushless; cordless handpiece |
|---|---|
| Speed | 100–1500 rpm |
| Torque | 0.4–4.2 Ncm |
| Contra-angle ratio | 6:1 |
| Head dimensions | 9.7 mm height; 8 mm diameter |
| Instrument weight | 106.8 g, handpiece plus contra-angle; not boxed weight |
5 easy buying checks for Woodpecker Endo Pace
Match continuous rotation or reciprocating movement to the exact file instructions and the operating modes available on the supplied motor.
Check the recommended working settings for the file sequence. The full adjustment range of a motor is not a setting recommendation for every canal.
Endo Pace does not become an integrated apex locator simply by being cordless. Confirm the matched external locator and connection required by the supplied configuration.
Select the original head and reduction ratio for this motor. Check how the head orientation fits the operator’s view and the tooth being treated.
Plan the charging location, approved adapter and component-specific reprocessing routine before the system enters the daily clinical workflow.
Care for Woodpecker Endo Pace
Plan contra-angle maintenance and handpiece surface care as separate tasks when setting up Woodpecker Endo Pace. Use the compatible head and the manufacturer’s instructions for cleaning, lubrication and reprocessing. Inspect the file-locking arrangement, keep charging contacts in good condition and use the appropriate adapter. The care instructions supplied with the exact revision determine which components can undergo each reprocessing method.
Woodpecker Endo Pace: questions before you order
Does Woodpecker Endo Pace have an integrated apex locator?
Its manual describes a preparation motor that can connect to a matched external apex locator. Confirm the locator and connection components separately when the practice requires combined preparation and measurement.
What does the 106.8 g weight describe?
It is the catalogue weight of the handpiece and contra-angle together. It does not establish the weight of the complete package, charger, adapter and shipping carton.
Can the head orientation be adjusted?
Yes. The catalogue describes a 360-degree rotatable mini contra-angle. Check that the supplied head matches the exact Endo Pace presentation being ordered.
How should Woodpecker Endo Pace be matched to files?
Compare the published speed, torque, movement direction and reciprocating capabilities with each file manufacturer’s instructions. Use the exact device manual when selecting and storing operating parameters.
